strength for prototyping rubber-like parts.
In Accordance With
EC Regulation 1907/ 2006, SVHC list in force
Directive EU 2011/ 65, 2015/ 863 & 2017/ 2102
2000/ 53/ EC
2002/ 96/ EC
2000/ 11/ EC
IMDS (mdsystem.com)
Documents
TDS HPR65
Technical data sheet of the HPR65. All mechanical and thermal properties of the all-purpose semi-rigid HPR65.
Documents
TDS Fastelast
Technical data sheet of the FASTELAST system. All mechanical properties for each hardness of the vacuum casting FASTELAST elastomer system.
Documents
TDS hpe system
Technical data sheet of the HPE system. All mechanical properties for each hardness of the versatile rubber-like HPE system.
| PRODUCT NAME | HPR65 | FASTELAST system | HPE System | PRODUCT NAME | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hardness | 65D | 35A | 45A | 50A | 60A | 65A | 75A | 80A | 86A | 93A | 40A | 50A | 60A | 70A | 85A | 35D | 55D | Hardness | (Shore) | |||
| Simulation of ² | HDPE/PP | rubber | rubber | rubber | Simulation of ² | |||||||||||||||||
| Colour of the cured material | transp. amber ³ | transp. | pearly transluscent | transparent amber ³ | Colour of the cured material | |||||||||||||||||
| Colourability ⁴ | Colourability ⁴ | |||||||||||||||||||||
| PROPERTIES | PROPERTIES | |||||||||||||||||||||
| Density | 1,12 | 1,04 | 1,06 | 1,07 | 1,08 | 1,07 | Density | (g/ cm3) | ||||||||||||||
| Flexural modulus | 450 | Flexural modulus | (MPa) | ISO 178 | ||||||||||||||||||
| Maximum flexural strength | 19 | Maximum flexural strength | (MPa) | ISO 178 | ||||||||||||||||||
| Elongation at break | 80 (ISO 527) | 530 | 700 | 730 | 750 | 770 | 715 | 880 | 680 | 616 | 270 | 400 | 500 | 800 | 900 | 460 | 325 | Elongation at break | (%) | ISO 37 | ||
| Tensile strength | 18 (ISO 527-1) | 1,8 | 3,7 | 4,9 | 7,1 | 8,3 | 14,5 | 15 | 26 | 22 | 2,7 | 3,6 | 6 | 7,2 | 13 | 14 | 16 | Tensile strength | (MPa) | ISO 37 | ||
| Impact resistance | 20 (notched) | Impact resistance | (kJ · m-2) | ISO 179 | ||||||||||||||||||
| Tear resistance | 7,8 | 13,4 | 20 | 25 | 30 | 54 | 55 | 64 | 66 | 11 | 18 | 27 | 40 | 54 | 58 | 70 | Tear resistance | (kN · m-1) | ISO 34 | |||
| Working temperature | − 20 ... + 85 | − 20 ... + 80 | Working temperature | (°C) | ||||||||||||||||||
| Mixing ratio (P : P/Iso : Iso) | 100 : 74 | 100 : 32 | 90 : 10 : 39 | 85 : 15 : 43 | 75 : 25 : 50 | 60 : 40 : 58 | 45 : 55 : 69 | 30 : 70 : 79 | 10 : 90 : 93 | 100 : 100 | 100 : 100 | 75 : 8 : 100 | 50 : 16 : 100 | 25 : 24 : 100 | 32 : 100 | 50 : 50 : 50 | 75 : 100 | Mixing ratio (P : P/Iso : Iso) | (in weight) | |||
| Mix viscosity at 25°C | 885 | 350 | 310 | 300 | 2000 | 2400 | 2700 | 3000 | 3200 | 1800 | 1300 | Mix viscosity at 25°C | (mPa · s) | |||||||||
| Pot life by 25°C | 13 | 16 | 12 | 13 | 10 | 8 | 10 | 7 | 6 | 60 | 55 | 50 | 45 | 40 | 25 | 18 | Pot life by 25°C | (min) | ||||
| Demoulding time by 70°C | 120 | 120 | 60 | 180 | 120 | Demoulding time by 70°C | (min) | |||||||||||||||
| Linear shrinkage thickness by 23°C | 7 | 5 | 5 | 7 | Linear shrinkage thickness by 23°C | (mm/ m) | ||||||||||||||||
| App. maximum wall thickness | ~ 100 | 30 | 20 | ~ 100 | App. maximum wall thickness | (mm) | ||||||||||||||||
| Mould life in silicone ⁶ | 30+ | 25 + | 40 + | Mould life in silicone ⁶ | (number of parts) | |||||||||||||||||
| STORAGE | STORAGE | |||||||||||||||||||||
| Standard & alternative packaging | 10,44 17,4 | 6 (P/ Iso) 12 (mix P & Iso) | 20 (P/ Iso) 6 (P/ Iso) 16 (mix P & Iso) | Standard & alternative packaging | (kg) | |||||||||||||||||
| Shelf life ⁷ | 18 | 12 (P) 6 (Iso) | 18 | Shelf life ⁷ | (months) | |||||||||||||||||
| Annotations | Casting by hand or machine High impact resistance Can be used for massive parts | Suitable for vacuum casting machine application Strong parts in a short demoulding time Colourable material | Casting by hand or machine Curing at room temperature or in oven Very good mechanical and chemical resistance | Annotations | ||||||||||||||||||
These plastics are PU thermoset elastomers. Depending on the chosen product and requested hardness, they can be two-component or three-component polyurethanes.
Their physical properties makes them soft materials with a high flexibility.
Unlike thermoplastic, they undergo chemical reaction called curing or cross-linking during the manufacturing process. Once they are set, they cannot be melted or reshaped. This bonding structure gives the material durability and more resistance to heat or chemical aggression.
These urethane materials are defined as elastomers as they have a rubber-like behaviour, with a high level of elasticity. This means that they can stretch several times and return to they original shape when the stress is removed. Moreover, being thermoset PUs, Synthene products show a great wearproofness, making them durable elastomers.
The Shore hardness of these elastic materials ranges from 35 Shore A for the softer Fastelast mix, to 65 Shore D for the semi-rigid HPR65.
The HPE and the HPR65 are suitable for injection or extrusion in RIM machine. For the HPE, depending on the requested hardness, the 2 polyols or the 2 isocyanates have to be pre-mixed before filling the tanks of the two-component mixing machine.
Pigments can be added to these elastomeric materials. However, it is important to note that the HPE et HPR65 materials are sensitive to UV light and will darken over time. The pigments must be solvent-based and should always be pre-mixed in the polyol component before mixing. We recommend an addition of 1% to 3% of pigment.
We recommend to use polyaddition silicone rubber to make the mould. In case of high scale application, aluminium mould can be considered.
The HPE, and particularly the hardnesses ranging from 60 Shore A to 85 Shore A, can be used to make durable polyurethane moulds. This tooling material is highly tear resistant and can be used to realise concrete moulding for example. With PU moulds instead of traditional silicone moulds, a subsequent amount of parts can be moulded in one tooling material.
All these materials should be casted or injected at room temperature. In order to reduce the viscosity of the HPE, it is possible to slightly heat the components to facilitate the castings, depending on your project. In that case, the potlife will also be reduced, it is therefore important to take this parameter into account.
The HPE can withstand temperatures between -40°C and +90°C
The Fastelast can be used between -20°C and +80°C
For the HPR65, we recommend applications between -20°C and +85°C
The colder the environment, the more rigid the product will be.
In case of warm temperatures, the product will soften. If the temperature is too hot, the material can be subject to deformation
The HPE are formulated to have an exceptional chemical resistance. It can be used underwater and automotive environments. Synthene has tested the HPE in several automotive fluids such as diesel, engine oil, aqueous solutions. It has also been used in many projects with submarine applications.
Synthene’s elastomers are very versatile and can be used in various industries such as Aerospace, Automotive, Leisure, Medical, Defense, Prototyping, Foundry…
The HPE system shows a good adhesion to metal, as long as the surface is properly cleaned, sanded and cleaned again with a proper solvent. All the process should be completely moisture-free. Using a compatible primer is necesary to guarantee a good level of bonding. After these steps, the casting can be realised on the metal part.
Rubbers like the HPE can be used for the fabrication of substrates, as a coating or protective layer for electronic parts for instance, or for composite materials.
